| Series | Nomex |
| Size | 295-380 |
| Material | Aluminum Alloy |
| Model No | Nor-Mex LE295-380 |
Series |
Nomex |
Size |
295-380 |
Material |
Aluminum Alloy |
Model No |
Nor-Mex LE295-380 |
Type of Product |
Chan Coupling |
Coupling Type |
LE Type |
Country of Origin |
Japan |
Other Dimensions |
D2: 170 mm, D5: 295 mm, lE: 150 mm |
Maximum Rotation Speed |
2250 RPM |
Overall Length (mm) |
210 |
Flywheel |
Parts (11): 13.155 Parts (17): 15.812 GD² Nm² (kg.m²) |
Monotaro ID |
37185522 |
Dimension M2 (mm) |
98 |
Dimension d4 (mm) |
348 |
Dimension S1 (mm) |
8±2.5 |
Regular Torque |
5440 Nm |
Shaft Hole Diameter d1 (Φmm) |
80～130 |
Mass (Kg) |
Parts (17): 19 Total: 60 |
Maximum Torque (Nm) |
9810 |
Dimension L1 |
52 mm |
Dimension L2 |
22 mm |
Number of Holes |
9 |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
