| Series | Nomex |
| Size | - |
| Material | Aluminum Alloy |
| Model No | Nor-Mex E148 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Series |
Nomex |
Size |
- |
Material |
Aluminum Alloy |
Model No |
Nor-Mex E148 |
Type of Product |
Chan Coupling |
Coupling Type |
E Type |
Country of Origin |
Japan |
Other Dimensions |
lE: 80 mm |
Maximum Rotation Speed |
4500 RPM |
Overall Length (mm) |
163.5 |
Flywheel |
Parts (11): 0.372 GD² Nm² (kg.m²) |
Monotaro ID |
37185172 |
Dimension M2 (mm) |
52 |
Dimension d4 (mm) |
148 |
Dimension S1 (mm) |
3.5±1 |
Outer Diameter (Φmm) |
148 |
Regular Torque |
409 Nm |
Shaft Hole Diameter d1 (Φmm) |
22～65 |
Mass (Kg) |
Parts (11): 6.1 Overall: 12.3 |
Maximum Torque (Nm) |
735 |
No. of Teeth |
7 |
Shaft hole diameter d2 (Φmm) |
22～65 |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
