Ships within 25 days
View
View
View
View
| Series | Nomex |
| Size | 415-575 |
| Material | Aluminum Alloy |
| Model No | Nor-Mex LE415-575 |
Series |
Nomex |
Size |
415-575 |
Material |
Aluminum Alloy |
Model No |
Nor-Mex LE415-575 |
Type of Product |
Chan Coupling |
Coupling Type |
LE Type |
Country of Origin |
Japan |
Other Dimensions |
D2: 270 mm, D5: 415 mm, lE: 200 mm |
Maximum Rotation Speed |
1500 RPM |
Overall Length (mm) |
273 |
Flywheel |
Parts (11): 75.709 Parts (17): 101.599 GD² Nm² (kg.m²) |
Monotaro ID |
37185556 |
Dimension M2 (mm) |
136 |
Dimension d4 (mm) |
528 |
Dimension S1 (mm) |
8±2.5 |
Regular Torque |
14700 Nm |
Shaft Hole Diameter d1 (Φmm) |
110～190 |
Mass (Kg) |
Parts (17): 55 Overall: 172.5 |
Maximum Torque (Nm) |
26500 |
Dimension L1 |
65 mm |
Dimension L2 |
30 mm |
Number of Holes |
10 |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
