| Series | Nomex |
| Size | - |
| Material | Aluminum Alloy |
| Model No | Nor-Mex E265 |
Series |
Nomex |
Size |
- |
Material |
Aluminum Alloy |
Model No |
Nor-Mex E265 |
Type of Product |
Chan Coupling |
Coupling Type |
E Type |
Country of Origin |
Japan |
Other Dimensions |
lE: 140 mm |
Maximum Rotation Speed |
2500 RPM |
Overall Length (mm) |
285.5 |
Flywheel |
Parts (11): 8.424 GD² Nm² (kg.m²) |
Monotaro ID |
37185224 |
Dimension M2 (mm) |
90 |
Dimension d4 (mm) |
265 |
Dimension S1 (mm) |
5.5±1 |
Outer Diameter (Φmm) |
265 |
Regular Torque |
4090 Nm |
Shaft Hole Diameter d1 (Φmm) |
70～120 |
Mass (Kg) |
Parts (11): 32.9 Overall: 66.3 |
Maximum Torque (Nm) |
7350 |
No. of Teeth |
10 |
Shaft hole diameter d2 (Φmm) |
70～120 |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
