| Series | Nomex |
| Size | - |
| Material | Aluminum Alloy |
| Model No | Nor-Mex E194 |
Series |
Nomex |
Size |
- |
Material |
Aluminum Alloy |
Model No |
Nor-Mex E194 |
Type of Product |
Chan Coupling |
Coupling Type |
E Type |
Country of Origin |
Japan |
Other Dimensions |
lE: 100 mm |
Maximum Rotation Speed |
3500 RPM |
Overall Length (mm) |
203.5 |
Flywheel |
Parts (11) ： 1.753 GD² Nm² (kg.m²) |
Monotaro ID |
37185197 |
Dimension M2 (mm) |
62 |
Dimension d4 (mm) |
194 |
Dimension S1 (mm) |
3.5±1 |
Outer Diameter (Φmm) |
194 |
Regular Torque |
1100 Nm |
Shaft Hole Diameter d1 (Φmm) |
32～85 |
Mass (Kg) |
Parts (11): 13 Overall: 26.3 |
Maximum Torque (Nm) |
1960 |
No. of Teeth |
9 |
Shaft hole diameter d2 (Φmm) |
32～85 |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
