| Series | Nomex |
| Size | - |
| Material | Aluminum Alloy |
| Model No | Nor-Mex E370 |
Series |
Nomex |
Size |
- |
Material |
Aluminum Alloy |
Model No |
Nor-Mex E370 |
Type of Product |
Chan Coupling |
Coupling Type |
E Type |
Country of Origin |
Japan |
Other Dimensions |
lE: 180 mm |
Maximum Rotation Speed |
1750 RPM |
Overall Length (mm) |
368 |
Flywheel |
Parts (11): 41.576 GD² Nm² (kg.m²) |
Monotaro ID |
37185251 |
Dimension M2 (mm) |
118 |
Dimension d4 (mm) |
370 |
Dimension S1 (mm) |
8±2.5 |
Outer Diameter (Φmm) |
370 |
Regular Torque |
9900 Nm |
Shaft Hole Diameter d1 (Φmm) |
100～170 |
Mass (Kg) |
Parts (11): 84 Overall: 169.5 |
Maximum Torque (Nm) |
17800 |
No. of Teeth |
11 |
Shaft hole diameter d2 (Φmm) |
100～170 |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
