Ships within 25 days
View
View
View
View
| Series | Nomex |
| Size | 330-430 |
| Material | Aluminum Alloy |
| Model No | Nor-Mex LE330-430 |
Series |
Nomex |
Size |
330-430 |
Material |
Aluminum Alloy |
Model No |
Nor-Mex LE330-430 |
Type of Product |
Chan Coupling |
Coupling Type |
LE Type |
Country of Origin |
Japan |
Other Dimensions |
D2: 200 mm, D5: 330 mm, lE: 160 mm |
Maximum Rotation Speed |
2000 RPM |
Overall Length (mm) |
224 |
Flywheel |
Parts (11): 24.431 Parts (17): 29.001 GD² Nm² (kg.m²) |
Monotaro ID |
37185531 |
Dimension M2 (mm) |
104 |
Dimension d4 (mm) |
390 |
Dimension S1 (mm) |
8±2.5 |
Regular Torque |
7080 Nm |
Shaft Hole Diameter d1 (Φmm) |
90～150 |
Mass (Kg) |
Parts (17): 28.5 Total: 87.7 |
Maximum Torque (Nm) |
12700 |
Dimension L1 |
56 mm |
Dimension L2 |
25 mm |
Number of Holes |
9 |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
