| Series | Nomex |
| Size | - |
| Material | Aluminum Alloy |
| Model No | Nor-Mex E415 |
Series |
Nomex |
Size |
- |
Material |
Aluminum Alloy |
Model No |
Nor-Mex E415 |
Type of Product |
Chan Coupling |
Coupling Type |
E Type |
Country of Origin |
Japan |
Other Dimensions |
lE: 200 mm |
Maximum Rotation Speed |
1500 RPM |
Overall Length (mm) |
408 |
Flywheel |
Parts (11): 75.709 GD² Nm² (kg.m²) |
Monotaro ID |
37185267 |
Dimension M2 (mm) |
136 |
Dimension d4 (mm) |
415 |
Dimension S1 (mm) |
8±2.5 |
Outer Diameter (Φmm) |
415 |
Regular Torque |
14700 Nm |
Shaft Hole Diameter d1 (Φmm) |
110～190 |
Mass (Kg) |
Parts (11): 117.5 Total: 237 |
Maximum Torque (Nm) |
26500 |
No. of Teeth |
12 |
Shaft hole diameter d2 (Φmm) |
110～190 |
Name of Manufacturer/Packer/Importer |
Mitsuboshi belting Ltd |
Import Country |
Direct Import from Japan |
