Ships within 5 days
View
View
View
View
| Power Source | DC |
| Operating Temperature | 0–40 °C |
| Frequency | 50 Hz |
| Type of Product | Off-Grid Solar Inverter |
Power Source |
DC |
Operating Temperature |
0–40 °C |
Frequency |
50 Hz |
Type of Product |
Off-Grid Solar Inverter |
Output Waveform |
Modified Sine Wave |
Rated Power |
500 W |
Input Voltage |
12 VDC |
Input Voltage Range |
15–60 VDC |
Output Voltage |
220 VAC |
Humidity |
0–80% |
Output Power |
Peak 600 W |
Supported Battery Type |
Lead-Acid / LiFePO4 |
Model No |
1xDIY-DC-AC-INV-500W |
Short Circuit Protection |
Output Auto-reboot after fault clearance |
Maximum Efficiency |
0.9 |
Maximum Input Power |
720 W |
Country of Origin |
China |
Name of Manufacturer/Packer/Importer |
Amicikart |
Inverter Capacity |
1000 VA |
Warranty Duration |
1 Year |
Built-in Controller |
600 W MPPT |
USB Output |
5 V / 2 A |
Maximum Charging Voltage |
14.2 VDC |
Input protection |
Anti-Reverse Connection |
Low Voltage Warning |
10.5 V ± 0.5 V |
High Voltage Recovery |
14.5 V ± 0.5 V |
Low Voltage Recovery |
12.4 V ± 0.5 V |
High Voltage Protection |
15 V ± 0.5 V |
Low Voltage Protection |
10 V ± 0.5 V |
Overload Protection |
110–125% load → 5s shutdown; ≥125% load → immediate shutdown |
Temperature Protection |
Output Heat dissipation >90 °C |
