| Type of Product | Sl-6100H |
| Model No | SL-6100-H-6P |
| Pack of | 1 Pcs |
| Country of Origin | Japan |
Type of Product |
Sl-6100H |
Model No |
SL-6100-H-6P |
Pack of |
1 Pcs |
Country of Origin |
Japan |
No. of Pole |
6P |
Name of Manufacturer/Packer/Importer |
Sato Parts Co., Ltd. |
Monotaro ID |
5587706 |
Import Country |
Direct Import from Japan |
Applicable Standard |
UL standard (compatible with field wiring), C-UL standard, TUV standard (conforms to IEC60947-7-1) |
Rated Voltage (V) |
300 |
Terminal Connection Type |
Screwless |
Current Rating, IEC (A) |
7 |
Standard Cable Stripping Length (mm) |
9 to 10 |
Current Rating, UL (A) |
7 |
Applicable Wire Range Twisted Wire (mm²) |
0.75 |
Suitable Cable Range |
Single line: Φ0.4mm ~ Φ1.2mm (AWG26 ~ AWG16 ), twisted <sup><sup>wire: 0.2mm 2 ~ 0.75mm 2 (AWG24</sup></sup> ~ AWG20), wire diameter Φ0.18mm more |
Terminal Spacing |
3.81 mm |
Applicable Wire Range Single Wire (mm) |
1 |
Type of Sign |
Printed board |
