Ships within 25 days
View
View
View
View
| Type of Product | Terminal Block Ml-40 |
| Model No | ML-40-S1BYS-2P |
| Pack of | 1 Pcs |
| Country of Origin | Japan |
Type of Product |
Terminal Block Ml-40 |
Model No |
ML-40-S1BYS-2P |
Pack of |
1 Pcs |
Country of Origin |
Japan |
No. of Pole |
2P |
Name of Manufacturer/Packer/Importer |
Sato Parts Co., Ltd. |
Monotaro ID |
39186262 |
Import Country |
Direct Import from Japan |
RoHS Directive |
Correspondence |
Insulation_Resistance (MΩ) |
1000 or more (DC500V) |
Applicable Standard |
UL standard (compatible with field wiring), CSA standard (CSA certified products must be specified when ordering) |
Rated Voltage (V) |
250 |
Terminal Connection Type |
screw |
Dimensions A (mm) |
17.14 |
Current Rating, UL (A) |
10 |
Terminal Spacing |
7.62 mm |
Type of Sign |
Printed board |
Insulator Material |
P.B.T.(UL94V-0) |
suitable crimping terminal |
PC terminal |
Body Color |
B (black) |
Withstand voltage (V / min) |
AC2000 |
Terminal Screw |
M3x6 |
