| Stroke (mm) | 10 |
| Monotaro ID | 2026063 |
| Type of Product | AC Solenoid |
| Model No | SA-1091 100V |
Stroke (mm) |
10 |
Monotaro ID |
2026063 |
Type of Product |
AC Solenoid |
Model No |
SA-1091 100V |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Mass (g) |
225, (Movable iron core) 68 |
Rated Voltage (V) |
AC 100 |
Withstand voltage (V / min) |
AC 1500 |
Insulation Type |
Class B insulation equivalent |
Starting Current (A) |
1.2 |
Insulation Resistance (MOhm) |
50 or more (DC500V) |
Rated Frequency (Hz) |
50/60 shared (2 leads) |
Suction Power |
5.8 N[0.6 Kgf] |
Acting Type |
tensile type |
Specifications |
Continuous rated current |
RoHS Directive |
Correspondence |
Holding Current (A) |
0.17 |
Endurance Times |
750,000 times |
