| Stroke (mm) | 15 |
| Monotaro ID | 2026088 |
| Type of Product | AC Solenoid |
| Model No | SA-2401 100V |
Stroke (mm) |
15 |
Monotaro ID |
2026088 |
Type of Product |
AC Solenoid |
Model No |
SA-2401 100V |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Mass (g) |
350, (Movable iron core) 95 |
Rated Voltage (V) |
AC 100 |
Withstand voltage (V / min) |
AC 2000 |
Insulation Type |
Class B insulation equivalent |
Starting Current (A) |
2.5 |
Insulation Resistance (MOhm) |
100 or more (DC 500 V) |
Rated Frequency (Hz) |
50/60 shared (2 leads) |
Suction Power |
9.8 N[1.0 Kgf] |
Acting Type |
tensile type |
Specifications |
Continuous rated current |
RoHS Directive |
Correspondence |
Holding Current (A) |
0.3 |
Endurance Times |
500,000 times |
