| Stroke (mm) | 10 |
| Monotaro ID | 2025634 |
| Type of Product | AC Solenoid Dual-Purpose Type |
| Model No | SA-992 100V |
Stroke (mm) |
10 |
Monotaro ID |
2025634 |
Type of Product |
AC Solenoid Dual-Purpose Type |
Model No |
SA-992 100V |
Import Country |
Direct Import from Japan |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Kokusai Dengyo Co., Ltd. |
Material |
Movable core: Cold-rolled silicon steel plate |
Mass (g) |
205, 65 (movable iron core) |
Rated Voltage (V) |
AC 100 V |
Withstand voltage (V / min) |
AC 1500 |
Insulation Type |
Class B insulation equivalent |
Starting Current (A) |
0.95 |
Insulation Resistance (MOhm) |
50 or more (DC500V) |
Rated Frequency (Hz) |
50/60 shared (2 leads) |
Suction Power |
4.9 N[0.5 Kgf] |
Acting Type |
Dual-use type |
Specifications |
Continuous rated current |
RoHS Directive |
Correspondence |
Holding Current (A) |
0.14000000000000001 |
Endurance Times |
750,000 times |
Surface Treatment |
Black baking |
Coil |
Coil insulation: Epoxy-impregnated polyester tape treatment (white), Coil: Polyester copper wire |
Stop |
Rubber: NBR (black) |
Lead Wire |
Heat-resistant vinyl wire (UL-1015), blue |
Temperature Rise |
85℃ or less |
