| Stroke (mm) | 10 |
| Monotaro ID | 40638003 |
| Type of Product | Pull Solenoid |
| Model No | CA12570880 |
Stroke (mm) |
10 |
Monotaro ID |
40638003 |
Type of Product |
Pull Solenoid |
Model No |
CA12570880 |
Import Country |
Direct Import from Japan |
Plunger Diameter |
12 mm |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Takaha Kiko |
Mass (g) |
260 |
Resistance (Ω) |
88 |
Dimension (mm) |
28x34x57.8 mm |
Maximum Stroke Length |
14 mm |
Type |
pull |
Overall Length (mm) |
57.8 (frame) |
Attracting Force (N) |
Continuous current: 4 / Current rate 6%: 23 |
Rated Voltage (V) |
DC 24 |
Energization Rate |
DC 24: Continuously energized |
