| Connection | 1/4 in G Female |
| Body Material | PP |
| Type | 45691 |
| Type of Product | Solenoid Valve |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Connection |
1/4 in G Female |
Body Material |
PP |
Type |
45691 |
Type of Product |
Solenoid Valve |
Series |
330 |
Country of Origin |
Ger mAny |
Operations |
Direct |
Flow Rate |
0.25m³/h |
Supply Voltage |
24 V DC |
Product Code |
440789 |
Maximum Operating Temperature |
+55°C |
Maximum Working Pressure |
4 bar |
Operating Temperature Range |
mAximum of +55°C |
Orifice Diameter |
3 mm |
Connection Size |
6.35 mm |
Valve Positions |
NO/NC |
Manufacturer Part Number |
78556 |
Name of Manufacturer/Packer/Importer |
Burkert |
Suitable Applications |
Aggressive Media |
Thread Standard or Connection Type |
G |
Connection Gender |
Female |
Connection Size (Inch) |
1/4 inch |
Maximum Closing Time |
20ms |
Maximum Opening Time |
20ms |
