Connection | 1/4 in G Female |
Body Material | Stainless Steel |
Type | 45691 |
Type of Product | Solenoid Valve |
Connection |
1/4 in G Female |
Body Material |
Stainless Steel |
Type |
45691 |
Type of Product |
Solenoid Valve |
Series |
330 |
Country of Origin |
Ger mAny |
Operations |
Direct |
Flow Rate |
0.14m³/h |
Supply Voltage |
24 V DC |
Product Code |
440745 |
Minimum Operating Temperature |
-30°C |
Maximum Operating Temperature |
+55°C |
Maximum Working Pressure |
6 bar |
Operating Temperature Range |
-30-+55°C |
Orifice Diameter |
3 mm |
Connection Size |
6.35 mm |
Valve Positions |
NO/NC |
Manufacturer Part Number |
41037 |
Name of Manufacturer/Packer/Importer |
Burkert |
Suitable Applications |
Aggressive Media, Gas, Liquid |
Thread Standard or Connection Type |
G |
Connection Gender |
Female |
Connection Size (Inch) |
1/4 inch |
Maximum Closing Time |
20ms |
Maximum Opening Time |
20ms |
