| Connection | 3/4 in G Female |
| Body Material | Brass |
| Type | 45690 |
| Type of Product | Solenoid Valve |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Connection |
3/4 in G Female |
Body Material |
Brass |
Type |
45690 |
Type of Product |
Solenoid Valve |
Series |
5282 |
Country of Origin |
Germany |
Operations |
Pilot |
Flow Rate |
6.5m³/h |
Supply Voltage |
230 V AC |
Product Code |
468033 |
Minimum Operating Temperature |
0°C |
Maximum Operating Temperature |
+55°C |
Maximum Working Pressure |
10 bar |
Operating Temperature Range |
0-+55°C |
Orifice Diameter |
20 mm |
Servo Assist |
Yes |
Connection Size |
19.05 mm |
Valve Positions |
NC |
Manufacturer Part Number |
134437 |
Name of Manufacturer/Packer/Importer |
Burkert |
Suitable Applications |
Neutral Media |
Thread Standard or Connection Type |
G |
Connection Gender |
Female |
Connection Size (Inch) |
3/4 inch |
Maximum Closing Time |
4s |
Maximum Opening Time |
0.8s |
