| Body Material | Zinc Alloy |
| Power Consumption | 4.5 W |
| Thread Size | 1/8 inch |
| Type of Product | Pneumatic Solenoid Valve |
Body Material |
Zinc Alloy |
Power Consumption |
4.5 W |
Thread Size |
1/8 inch |
Type of Product |
Pneumatic Solenoid Valve |
Series |
V04 |
Country of Origin |
Czech Republic |
Maximum Operating Pressure |
10bar |
Function |
3/2 |
No. of Port |
3/2 |
Mounting Style |
Inline, Manifold |
Solenoid |
Yes |
Product Code |
2273468 |
Minimum Operating Pressure |
0 bar |
Minimum Operating Temperature |
-20°C |
Maximum Operating Temperature |
+50°C |
Actuation Type |
Solenoid/Spring |
Maximum Flow Rate |
120 L/min |
Thread Standard |
G |
Manufacturer Part Number |
V04A486L-B623A |
Name of Manufacturer/Packer/Importer |
Norgren |
Thread Size (Metric) |
3.18 mm |
Connection Port Thread |
G 1/8 |
Solenoid Voltage |
24 V DC |
Pack of |
1 Pc |
