| Type | Isolated |
| Load Voltage | 3 VDC to 48 VDC |
| Type of Product | Solid State Relays |
| Height | 22.6 mm |
Type |
Isolated |
Load Voltage |
3 VDC to 48 VDC |
Type of Product |
Solid State Relays |
Height |
22.6 mm |
Width |
44.5 mm |
Series |
DC60S/SA |
Country of Origin |
India |
Length |
57.3 mm |
Maximum Operating Temperature |
+80°C |
Minimum Operating Temperature |
-30°C |
Output Type |
Bi-Polar Transistor |
Input Current |
2.2 mA to 25 mA |
IP Rating |
IP00 |
Name of Manufacturer/Packer/Importer |
Crydom |
Control Voltage Range |
3.5 VDC to 32 VDC |
Ordering ID |
558-DC60S3-B |
Manufacturer Part Number |
DC60S3-B |
Mounting Style |
Panel Mount |
RoHS Compliant |
Yes |
Load Current Rating |
3 A |
Data Sheet |
https://www.sensata.com/sites/default/files/a/sensata-dc60%20series-panel%20mount%20relay-datasheet.pdf |
Relay Contact Form |
1 Form B (SPST-NC) |
