| Load Voltage | 48-280 V AC |
| Type of Product | Solid State Relay |
| Height | 20.5 mm |
| Depth | 45.7 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
48-280 V AC |
Type of Product |
Solid State Relay |
Height |
20.5 mm |
Depth |
45.7 mm |
Operating Temperature Range |
-30-+80°C |
Mounting Type |
Panel Mount |
Series |
KSI |
Maximum Load Current |
0.41666666666666669 |
Country of Origin |
China |
Special Features |
Build-In MOV/TVS Option, DC Control, Dielectric Strength, LED Indicator, TRIAC or SCR Output |
Length |
58.4 mm |
Leakage Current |
5 mA |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-30°C |
Dimension |
58.4x45.7x20.5 mm |
Relay Type |
Single Phase |
Output Device |
SCR, Triac |
Switch Type |
Random |
Name of Manufacturer/Packer/Importer |
i-Autoc |
Maximum Control Voltage |
32 V DC |
Minimum Control Voltage |
4 V DC |
Maximum Turn On Time |
1ms |
Control Voltage Range |
4-32 V DC |
Maximum Load Voltage |
280 V AC |
Minimum Load Voltage |
48 V AC |
Product Code |
1640575 |
Manufacturer Part Number |
KSI240D10R-L |
Standards Met |
CCCs, CE, CULus, TUV |
