| Type of Product | Solid State Relay |
| Height | 112.5 mm |
| Depth | 30.5 mm |
| Operating Temperature Range | -30-+80°C |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Solid State Relay |
Height |
112.5 mm |
Depth |
30.5 mm |
Operating Temperature Range |
-30-+80°C |
Mounting Type |
DIN Rail or Panel |
Series |
KSV |
Country of Origin |
China |
Special Features |
Built-In RC Snubber Circuit, Dielectric Strength 4000 VACrmsLED Indication, Integerated Heatsink, SCR Output, Zero Crossing or Random-On Switching |
Length |
100 mm |
Maximum Operating Temperature |
+80°C |
Terminal Type |
PCB Pin |
Minimum Operating Temperature |
-30°C |
Dimension |
100x30.5x112.5 mm |
Relay Type |
Single Phase |
Coil Voltage |
24 V DC |
Input Current |
15 (dc) mA, 25 (ac) mA |
Name of Manufacturer/Packer/Importer |
i-Autoc |
Product Code |
1353329 |
Manufacturer Part Number |
KSV240D10-LM Â Â Â |
Standards Met |
CE |
Turn On Time |
10 (DC), 40 (AC) |
Turn Off Time |
10 (DC) ms, 40 (AC) ms |
