Ships within 19 days
Model No
View
View
View
View
| Model No | G6SU-2F-Y-TRDC24 |
| Mass (g) | About 2 |
| Shock Resistance | 1000 m/s² |
| Ambient Humidity to Use | 5-85%RH |
Model No |
G6SU-2F-Y-TRDC24 |
Mass (g) |
About 2 |
Shock Resistance |
1000 m/s² |
Ambient Humidity to Use |
5-85%RH |
Monotaro ID |
66553375 |
Type of Product |
Surface Mount Relay |
No. of Pole |
2 Poles |
Terminal Shape |
External L-Shaped Surface Mount Terminals |
Standard |
UL, CSA standard, BSI (EN62368-1) certification |
Series |
G6S Series |
Country of Origin |
China |
Contact Configuration |
2C |
Import Country |
Direct Import from Japan |
Type of Sign |
Board mounting |
Function |
(Relay) Single-Winding Latching Type |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Height (mm) |
9.1999999999999993 |
Protection Class |
Plastic seal type |
Operation Ambient Temperature (°C) |
-40 to +70 (with no icing or condensation) |
Pack of |
800 Pcs |
Length (mm) |
15 |
Width (mm) |
7.5 |
Insulation Resistance (MOhm) |
1000 or more (with DC 500 V mega) |
Vibration Resistance (Destruction) |
10 to 55 to 10 Hz, single amplitude 2.5 mm (double amplitude 5 mm) |
Vibration Resistance (Malfunction) |
10 - 55 - 10Hz Single amplitude 1.65mm (double amplitude 3.3mm) |
Shock Resistance (Malfunction) |
750m/s² |
Rated Coil Voltage |
DC 24 V |
Contact Resistance (ohm) |
75 mΩ or less (DC1V 10mA voltage drop method) |
