| Type | Solid state/relay |
| Model No | G3PF-525B-STB-DC24 |
| Mass (g) | About 400 |
| Voltage Drop when Output Turned ON | Main circuit section/1.8V (RMS) or less Alarm output section/1.5V or less |
Type |
Solid state/relay |
Model No |
G3PF-525B-STB-DC24 |
Mass (g) |
About 400 |
Voltage Drop when Output Turned ON |
Main circuit section/1.8V (RMS) or less Alarm output section/1.5V or less |
Rated Load Voltage (V) |
AC 200 to 480 (50/60 Hz) |
Insulation Type |
Phototriac coupler |
Operation Indicator Lamp |
Yes |
Operating Voltage Range (V) |
DC 20.4 to 26.4 |
Rated Voltage (V) |
DC24 |
Suitable Load of Output |
2 to 25 Amp AC 200 to 480 V |
Monotaro ID |
46584772 |
Type of Product |
Solid State Relay |
Applicable Standard |
CSA (File No. LR35535), TUV (File No. R50124941, EN60947-4-3) |
Input Voltage (V) |
(Use) DC 9.6 to 26.4 |
Terminal Shape |
Small negative terminal (detachable) |
Series |
G3PF Series |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Operation Mode |
NPN open collector (ON when an error is detected) |
Input Method |
Voltage input |
Current Consumption (mA) |
DC 50 or less (at 24 V DC ) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Rated Input Voltage (V) |
DC 12 to 24 |
Operation Ambient Temperature (°C) |
-20 to +60 (with no icing or condensation) |
Specifications |
Collector breakdown voltage when OFF (alarm output part) / DC30V or less |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
