Ships within 25 days
View
View
View
View
| Type | Solid state/relay |
| Model No | G3CN-202PL1-US-DC24 |
| Load Voltage | AC 75 to 264 V |
| Mass (g) | About 25 |
Type |
Solid state/relay |
Model No |
G3CN-202PL1-US-DC24 |
Load Voltage |
AC 75 to 264 V |
Mass (g) |
About 25 |
Voltage Drop when Output Turned ON |
1.6 V (RMS) or less |
Rated Load Voltage (V) |
AC 100 to 240 |
Insulation Type |
Photo triac |
Operation Indicator Lamp |
None |
Return Voltage |
DC 1 V or more |
Equipped with/without Zero Cross Function |
None |
Input Impedance |
2 kΩ±20% |
Operating Voltage Range (V) |
DC 24 |
Rated Voltage (V) |
DC 24 |
Ambient Humidity to Use |
45 to 85%Rh |
Leakage Current (mA) |
5 or less (at 50 V DC) |
Suitable Load of Output |
2 Amp AC 100 to 240 V |
Monotaro ID |
46624767 |
Type of Product |
Solid State Relay |
Terminal Shape |
Printed Circuit Board Terminal |
Shape |
Vertical type |
Storage Temperature Range |
-30 to +100℃ (with no icing or condensation) |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-30 to +80 (with no icing or condensation) |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
