| Type of Product | Solid State Relay |
| Height | 1.8 mm (0.071 in) |
| Width | 2.04 mm (0.08 in) |
| Series | G3VM |
Type of Product |
Solid State Relay |
Height |
1.8 mm (0.071 in) |
Width |
2.04 mm (0.08 in) |
Series |
G3VM |
Length |
3.8 mm (0.15 in) |
Maximum Operating Temperature |
+85°C |
Minimum Operating Temperature |
-20°C |
Output Type |
MOSFET |
Input Current |
50 mA |
Name of Manufacturer/Packer/Importer |
Omron Electronics |
Control Voltage Range |
1 VDC to 1.3 VDC |
Ordering ID |
653-G3VM-21LR11 |
Manufacturer Part Number |
G3VM-21LR11 |
Mounting Style |
PCB Mount |
RoHS Compliant |
RoHS Compliant |
Load Current Rating |
900 mA |
Relay Contact Form |
1 Form A (SPST-NO) |
Packaging Type |
Reel, Cut Tape, MouseReel |
Load Voltage Rating |
20 VAC, 20 VDC |
Package/Case |
SSOP-4 |
