| Type of Product | Solid State Relay |
| Height | 3.4 mm (0.134 Inch) |
| Width | 6.4 mm (0.252 Inch) |
| Series | AQ-H |
Type of Product |
Solid State Relay |
Height |
3.4 mm (0.134 Inch) |
Width |
6.4 mm (0.252 Inch) |
Series |
AQ-H |
Country of Origin |
India |
Length |
9.78 mm (0.385 Inch) |
Maximum Operating Temperature |
+85�C |
Minimum Operating Temperature |
-30�C |
Output Type |
PhotoTriac |
Input Current |
50 mA |
Name of Manufacturer/Packer/Importer |
Panasonic |
Control Voltage Range |
1.21 V DC |
Ordering ID |
769-AQH3213A |
Manufacturer Part Number |
AQH3213A |
Mounting Style |
PCB Mount |
RoHS Compliant |
Yes By Exemption |
Load Current Rating |
1.2 Amp |
Data Sheet |
https://www3.panasonic.biz/ac/e_download/control/relay/solid-state/catalog/semi_eng_aqh.pdf |
Relay Contact Form |
1 Form A (SPST-NO) |
Packaging Type |
Tube |
Package / Case |
SMD DIP-8 |
