| Model No | AQ80233 |
| Load Voltage | AC 75-250 V |
| Shock Resistance | 980 m/s² or more (up/down, left/right, front/back, 5 times in each direction) |
| Insulation Resistance | Between input and output: 10⁹Ω or more (at 500 V DC) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
AQ80233 |
Load Voltage |
AC 75-250 V |
Shock Resistance |
980 m/s² or more (up/down, left/right, front/back, 5 times in each direction) |
Insulation Resistance |
Between input and output: 10⁹Ω or more (at 500 V DC) |
Operating Time (ms) |
1 or less |
Return Voltage |
Input side: 1.2V or more |
Equipped with/without Zero Cross Function |
No |
Rated Voltage (V) |
Input side: DC12 |
Return Time (ms) |
1/2 cycle +1 or less |
Monotaro ID |
73906726 |
Type of Product |
Solid State Relay |
Standard |
UL, CSA, TUV |
Operation Indicator |
Random turn-on, zero-cross turn-off |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Withstand Voltage |
Input-output: 3000 Vrms (1 minute) |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Storage Temperature |
-30 to 100 ℃ (but no freezing or condensation) |
Pack of |
20 Pcs |
Operating voltage (V) |
9.6 to 14.4 |
Specifications |
●Repeated peak off-state voltage (output side): 600V, ●Surge current (output side): 30A (60Hz 1 cycle), ●Leakage current when open (output side): 5mA or less (when 200 Vrms is applied) (at 60Hz), ●Voltage drop when closed (output side): 1.6V or less (when maximum load is applied), ●Critical off-state voltage rise rate (output side): 50V/μs (at ambient temperature of 80°C) |
Contact Spacing |
5.08 |
Output Frequency (Hz) |
45 to 65 |
Vibration Resistance (Destruction) |
10-55 Hz double amplitude 3 mm (up and down, left and right, front and back, 10 minutes in each direction) |
Thickness (mm) |
9 |
Vibration Resistance (Malfunction) |
10-55 Hz double amplitude 3 mm (up/down, left/right, front/back, 1 hour each direction) |
Shock Resistance (Malfunction) |
980 m/s² or more (up/down, left/right, front/back, 4 times in each direction) |
