| Type of Product | Solid State Relay |
| Height | 2.9 mm (0.114 Inch) |
| Width | 4.78 mm (0.188 Inch) |
| Series | AQY |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Solid State Relay |
Height |
2.9 mm (0.114 Inch) |
Width |
4.78 mm (0.188 Inch) |
Series |
AQY |
Country of Origin |
India |
Length |
6.4 mm (0.252 Inch) |
Maximum Operating Temperature |
+85�C |
Minimum Operating Temperature |
-40�C |
Output Type |
Photo MOSFET |
Input Current |
50 mA |
Name of Manufacturer/Packer/Importer |
Panasonic |
Voltage Rating |
350 V AC, 350 V DC |
Control Voltage Range |
1.25 V DC |
Ordering ID |
769-AQY210HLA |
Manufacturer Part Number |
AQY210HLA |
Mounting Style |
PCB Mount |
RoHS Compliant |
Yes |
Load Current Rating |
120 mA |
Data Sheet |
https://www3.panasonic.biz/ac/e_download/control/relay/photomos/catalog/semi_eng_gu1a_aqy21_hl.pdf |
Relay Contact Form |
1 Form A (SPST-NO) |
Packaging Type |
Tube |
Package / Case |
SMD DIP-4 |
