| Type of Product | Solid State Relay |
| Height | 3.9 mm (0.154 Inch) |
| Width | 6.4 mm (0.252 Inch) |
| Series | AQV |
Type of Product |
Solid State Relay |
Height |
3.9 mm (0.154 Inch) |
Width |
6.4 mm (0.252 Inch) |
Series |
AQV |
Country of Origin |
India |
Length |
8.88 mm (0.35 Inch) |
Maximum Operating Temperature |
+85�C |
Minimum Operating Temperature |
-40�C |
Output Type |
Photo MOSFET |
Input Current |
50 mA |
Name of Manufacturer/Packer/Importer |
Panasonic |
Voltage Rating |
40 V DC |
Control Voltage Range |
2.3 V DC |
Ordering ID |
769-AQV101 |
Manufacturer Part Number |
AQV101 |
Mounting Style |
PCB Mount |
RoHS Compliant |
Yes By Exemption |
Load Current Rating |
700 mA |
Data Sheet |
https://www3.panasonic.biz/ac/e_download/control/relay/photomos/catalog/semi_eng_hf1a_aqv10_20.pdf |
Relay Contact Form |
1 Form A (SPST-NO) |
Packaging Type |
Tube |
Package / Case |
DIP-6 |
