| Model No | AQ81229 |
| Load Voltage | AC 75-250 V |
| Operating Time (ms) | 1 or less |
| Return Voltage | Input side: 0.5V or more |
Model No |
AQ81229 |
Load Voltage |
AC 75-250 V |
Operating Time (ms) |
1 or less |
Return Voltage |
Input side: 0.5V or more |
Equipped with/without Zero Cross Function |
No |
Rated Voltage (V) |
Input side: DC5 |
Return Time (ms) |
1/2 cycle +1 or less |
Monotaro ID |
73906954 |
Type of Product |
Solid State Relay |
Standard |
UL, CSA, TUV |
Operation Indicator |
Non-zero crossing |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Withstand Voltage |
Input-output: 3000 Vrms (1 minute) |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Storage Temperature |
-30 to 100 ℃ (but no freezing or condensation) |
Pack of |
20 Pcs |
Operating voltage (V) |
4 to 6 |
Specifications |
Surge current (output side): 30A Open circuit leakage current (output side): 2.5mA or less (when 100 V AC is applied) |
Contact Spacing |
7.62 |
