| Type of Product | Solid State Relay |
| Height | 1.8 mm (0.071 Inch) |
| Width | 2.65 mm (0.104 Inch) |
| Series | AQY |
Type of Product |
Solid State Relay |
Height |
1.8 mm (0.071 Inch) |
Width |
2.65 mm (0.104 Inch) |
Series |
AQY |
Country of Origin |
India |
Length |
4.45 mm (0.175 Inch) |
Maximum Operating Temperature |
+85�C |
Minimum Operating Temperature |
-40�C |
Output Type |
Photo MOSFET |
Input Current |
50 mA |
Name of Manufacturer/Packer/Importer |
Panasonic |
Voltage Rating |
40 V AC, 40 V DC |
Control Voltage Range |
1.14 V DC |
Ordering ID |
769-AQY221R2VW |
Manufacturer Part Number |
AQY221R2VW |
Mounting Style |
PCB Mount |
RoHS Compliant |
Yes |
Load Current Rating |
250 mA |
Data Sheet |
https://www3.panasonic.biz/ac/e_download/control/relay/photomos/catalog/semi_eng_rf1a_aqy22_v_cr10.pdf |
Relay Contact Form |
1 Form A (SPST-NO) |
Packaging Type |
Reel, Cut Tape |
Package / Case |
SSOP-4 |
