| Load Voltage | 12 to 280 V AC |
| Type of Product | Solid State Relay |
| No. of Pole | 1 |
| Height | 81 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
12 to 280 V AC |
Type of Product |
Solid State Relay |
No. of Pole |
1 |
Height |
81 mm |
Depth |
65 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
DIN Rail |
Series |
GMS |
Maximum Load Current |
5 A RMS |
Country of Origin |
Mexico |
Capacitance |
6 pF |
Special Features |
Barrier Strips Accept 14 to 28 AWG Wire, Industry standard Color Coding Black (AC Output) Red (DC Output) |
Length |
17.5 mm |
Leakage Current |
0.1 mA RMS |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-30°C |
Dimension |
17.5x65x81 mm |
Relay Type |
Solid State Relay |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
50 mA RMS, 50 mA RMS |
Minimum Control Voltage |
4 V DC |
Maximum Turn On Time |
8.33 ms |
Control Voltage Range |
4 to 32 V DC |
Maximum Load Voltage |
280 V AC |
Minimum Load Voltage |
12 V AC |
Product Code |
1450529 |
Pack of |
1 Pc |
Manufacturer Part Number |
84130105 |
Standards Met |
CE, cUL Recognised E46203, UL Recognised E46203 |
