| Load Voltage | 48 to 600 VRMS |
| Type of Product | Solid State Relay |
| No. of Pole | 1 |
| Height | 91.9 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
48 to 600 VRMS |
Type of Product |
Solid State Relay |
No. of Pole |
1 |
Height |
91.9 mm |
Depth |
116.5 mm |
Operating Temperature Range |
-40 to +80°C |
Mounting Type |
DIN Rail |
Series |
DR22 |
Maximum Load Current |
30 A |
Country of Origin |
Mexico |
Capacitance |
8 pF |
Special Features |
1 kHz PWM Frequency, IP20 Touch Safe Housing, LED Input Status Indicator |
Length |
22.5 mm |
Leakage Current |
1 mA |
Maximum Operating Temperature |
+80°C |
Contact Configuration |
SP |
Terminal Type |
Screw |
Minimum Operating Temperature |
-40°C |
Dimension |
22.5x116.5x91.9 mm |
Relay Type |
Nove 22 Solid State Relay |
Output Device |
MOSFET |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
5 mA |
Minimum Control Voltage |
4 V DC |
Maximum Turn On Time |
0.075 ms |
Control Voltage Range |
4 to 32 V DC |
Maximum Load Voltage |
600 V RMS |
Minimum Load Voltage |
48 V RMS |
Product Code |
9107321 |
Pack of |
1 Pc |
Manufacturer Part Number |
DR2260D30V |
Standards Met |
CE, cULus, cUS, IEC, ISO |
