| Load Voltage | 0 to 48 V DC |
| Type of Product | Solid State Relay |
| Height | 15 mm |
| Depth | 5 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
0 to 48 V DC |
Type of Product |
Solid State Relay |
Height |
15 mm |
Depth |
5 mm |
Operating Temperature Range |
-20 to +80°C |
Mounting Type |
PCB Mount |
Series |
CN |
Maximum Load Current |
0.1 A |
Country of Origin |
Mexico |
Capacitance |
1.5 pF |
Length |
28 mm |
Leakage Current |
0.001 mA |
Maximum Operating Temperature |
+80°C |
Contact Configuration |
SPST |
Terminal Type |
Through Hole |
Minimum Operating Temperature |
-20°C |
Dimension |
28x5x15 mm |
Relay Type |
Solid State Relay |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
12 V DC |
Minimum Load Current |
1 mA |
Minimum Control Voltage |
3 V DC |
Maximum Turn On Time |
0.02 ms |
Control Voltage Range |
3 to 12 V DC |
Maximum Load Voltage |
48 V DC |
Minimum Load Voltage |
0 V DC |
Product Code |
7203953 |
Pack of |
1 Pc |
Package Type |
Mini-SIP |
Manufacturer Part Number |
CN048D05 |
