| Load Voltage | 1 to 100 V DC |
| Type of Product | Solid State Relay |
| No. of Pole | 1 |
| Height | 22.6 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
1 to 100 V DC |
Type of Product |
Solid State Relay |
No. of Pole |
1 |
Height |
22.6 mm |
Depth |
57.3 mm |
Operating Temperature Range |
-40 to +100°C |
Mounting Type |
Panel Mount |
Series |
1-DC |
Maximum Load Current |
40 A dc |
Country of Origin |
Mexico |
Capacitance |
8 pF |
Special Features |
DC Control, Epoxy-Free Design, Improved SEMS Screw & Washer, Redesigned Housing with Anti-Rotation Barriers |
Length |
44.5 mm |
Leakage Current |
0.3 mA |
Maximum Operating Temperature |
+100°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-40°C |
Dimension |
44.5x57.3x22.6 mm |
Relay Type |
Solid State Relay |
Output Device |
MOSFET |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
1 mA |
Minimum Control Voltage |
3.5 V DC |
Maximum Turn On Time |
0.1 ms |
Control Voltage Range |
3.5 to 32 V DC |
Maximum Load Voltage |
100 V DC |
Minimum Load Voltage |
1 V DC |
Product Code |
1450573 |
Pack of |
1 Pc |
Manufacturer Part Number |
D1D40K |
Standards Met |
CE, cULus Recognised E116950, EMC Compliant, EN 60950-1, IEC, IEC 61000-4-2, IEC 61000-4-4, UL, UL 94 V-0 |
