| Load Voltage | 0 to 24 V DC |
| Type of Product | Solid State Interface Relay |
| Height | 80 mm |
| Depth | 6.1 mm |
Load Voltage |
0 to 24 V DC |
Type of Product |
Solid State Interface Relay |
Height |
80 mm |
Depth |
6.1 mm |
Operating Temperature Range |
-25 to +60°C |
Mounting Type |
DIN Rail |
Maximum Load Current |
3.5 A |
Country of Origin |
Mexico |
Length |
92.6 mm |
Leakage Current |
0.001 mA |
Maximum Operating Temperature |
+60°C |
Minimum Operating Temperature |
-25°C |
Dimension |
92.6x6.1x80 mm |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
12 V DC |
Minimum Load Current |
1 mA |
Minimum Control Voltage |
3 V DC |
Maximum Turn On Time |
120 μs |
Control Voltage Range |
3 to 12 V DC |
Maximum Load Voltage |
24 V DC |
Minimum Load Voltage |
0 V DC |
Product Code |
7203978 |
Pack of |
1 Pc |
Manufacturer Part Number |
DRA-CN024D05 |
