| Load Voltage | 8 to 30 V DC |
| Type of Product | Solid State Relay |
| No. of Pole | 1 |
| Height | 96.1 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
8 to 30 V DC |
Type of Product |
Solid State Relay |
No. of Pole |
1 |
Height |
96.1 mm |
Depth |
59.5 mm |
Operating Temperature Range |
-25 to +70°C |
Mounting Type |
DIN Rail |
Maximum Load Current |
1.5 mA |
Country of Origin |
Mexico |
Capacitance |
14 pF |
Special Features |
Easy Installation & Removal, IP20 Touch-Safe Housing, LED Status Indicators, No Mains Voltage/ Open Load & SSR Short Circuit Detection, Under & Overcurrent Detection |
Length |
21.5 mm |
Leakage Current |
1 μA |
Maximum Operating Temperature |
+70°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-25°C |
Dimension |
21.5x59.5x96.1 mm |
Relay Type |
Solid State Relay |
Switch Type |
Selector Switch |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
100 μA |
Minimum Control Voltage |
4 V DC |
Range |
NOVA22 |
Maximum Turn On Time |
15 ms |
Control Voltage Range |
4 to 32 V DC |
Maximum Load Voltage |
30 V DC |
Minimum Load Voltage |
8 V DC |
Product Code |
1450586 |
Pack of |
1 Pc |
Manufacturer Part Number |
DRML1 |
Standards Met |
CE, cULus Recognised E116950, EMC Compliant, IEC |
