| Load Voltage | 48 to 530 VRMS |
| Type of Product | Solid State Relay |
| Height | 115.8 mm |
| Depth | 152.4 mm |
Load Voltage |
48 to 530 VRMS |
Type of Product |
Solid State Relay |
Height |
115.8 mm |
Depth |
152.4 mm |
Operating Temperature Range |
-40 to +80°C |
Mounting Type |
Panel Mount |
Maximum Load Current |
82.5 A RMS |
Country of Origin |
Mexico |
Length |
152.4 mm |
Leakage Current |
10 mA RMS |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-40°C |
Dimension |
152.4x152.4x115.8 mm |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
0.05 A RMS |
Minimum Control Voltage |
3 V DC |
Maximum Turn On Time |
1/2 cycle |
Control Voltage Range |
3 to 32 V DC |
Maximum Load Voltage |
530 V AC |
Minimum Load Voltage |
48 V AC |
Product Code |
7034662 |
Pack of |
1 Pc |
Manufacturer Part Number |
HS053-D53TP50D |
