| Load Voltage | 1 to 72 V DC |
| Type of Product | Solid State Relay |
| Height | 58.8 mm |
| Depth | 30.9 mm |
Load Voltage |
1 to 72 V DC |
Type of Product |
Solid State Relay |
Height |
58.8 mm |
Depth |
30.9 mm |
Operating Temperature Range |
-40 to +100°C |
Mounting Type |
Surface Mount |
Series |
PowerPlus DC |
Maximum Load Current |
40 A |
Country of Origin |
Mexico |
Capacitance |
8 pF |
Special Features |
LED Status Indicator |
Length |
44.5 mm |
Leakage Current |
0.15 mA |
Maximum Operating Temperature |
+100°C |
Contact Configuration |
SPST |
Terminal Type |
Screw |
Minimum Operating Temperature |
-40°C |
Dimension |
44.5x30.9x58.8 mm |
Relay Type |
Solid State Relay |
Output Device |
MOSFET |
Switch Type |
Instantaneous |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
2.5 mA |
Minimum Control Voltage |
4 V DC |
Maximum Turn On Time |
0.075 ms |
Control Voltage Range |
4 to 32 V DC |
Maximum Load Voltage |
72 V DC |
Minimum Load Voltage |
1 V DC |
Product Code |
7569531 |
Pack of |
1 Pc |
Package Type |
Panel Mount |
Manufacturer Part Number |
DC100D40C |
Standards Met |
CE, EN 60950-1, UL |
