| Load Voltage | 5 to 60 V DC |
| Type of Product | Solid State Relay |
| Height | 81 mm |
| Depth | 65 mm |
Load Voltage |
5 to 60 V DC |
Type of Product |
Solid State Relay |
Height |
81 mm |
Depth |
65 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
DIN Rail |
Series |
GMS |
Maximum Load Current |
3 A |
Country of Origin |
Mexico |
Capacitance |
4 pF |
Special Features |
LED Input Status Indicator |
Length |
17.5 mm |
Leakage Current |
10 μA |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-30°C |
Dimension |
17.5x65x81 mm |
Output Device |
Triac |
Switch Type |
Zero Voltage Turn-On |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Control Voltage |
4 V DC |
Maximum Turn On Time |
0.05 ms |
Control Voltage Range |
4 to 32 V DC |
Maximum Load Voltage |
60 V DC |
Minimum Load Voltage |
5 V DC |
Product Code |
1707322 |
Pack of |
1 Pc |
Manufacturer Part Number |
84130104 |
