| Load Voltage | 48 to 600 VRMS |
| Type of Product | Solid State Relay |
| Height | 91.2 mm |
| Depth | 123.4 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
48 to 600 VRMS |
Type of Product |
Solid State Relay |
Height |
91.2 mm |
Depth |
123.4 mm |
Operating Temperature Range |
-20 to +80°C |
Mounting Type |
DIN Rail |
Series |
CTR |
Maximum Load Current |
25 A RMS |
Country of Origin |
Mexico |
Capacitance |
8 pF |
Special Features |
LED Status Indicator, SCR Output For Heavy Industrial Loads |
Length |
90 mm |
Leakage Current |
0.25 mA RMS |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-20°C |
Dimension |
90x123.4x91.2 mm |
Relay Type |
Solid State Relay |
Output Device |
SCR |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
0.1 A RMS |
Minimum Control Voltage |
4 V DC |
Maximum Turn On Time |
1/2 cycle |
Control Voltage Range |
4 to 32 V DC |
Maximum Load Voltage |
600 V RMS |
Minimum Load Voltage |
48 V RMS |
Product Code |
7204066 |
Pack of |
1 Pc |
Manufacturer Part Number |
CTRD6025 |
Standards Met |
CE, RoHS Compliant |
