| Load Voltage | 24 to 280 V AC |
| Type of Product | Solid State Relay |
| Height | 58.4 mm |
| Depth | 33 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
24 to 280 V AC |
Type of Product |
Solid State Relay |
Height |
58.4 mm |
Depth |
33 mm |
Operating Temperature Range |
-40 to +80°C |
Mounting Type |
Panel Mount |
Series |
CW24 |
Maximum Load Current |
25 A |
Country of Origin |
Mexico |
Capacitance |
8 pF |
Special Features |
LED Status Indicator, EMC Compliant To Level 3, Removable IP20 Touch Safe Cover, Epoxy Free Design |
Length |
45.7 mm |
Leakage Current |
1 mA |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-30°C |
Dimension |
45.7x33x58.4 mm |
Relay Type |
Solid State Relay |
Output Device |
SCR |
Switch Type |
Instantaneous |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
48 V DC, 280 V AC |
Minimum Load Current |
0.15 A |
Minimum Control Voltage |
20V AC/DC |
Maximum Turn On Time |
17 ms |
Control Voltage Range |
20 to 280 V AC, 20 to 48 V DC |
Maximum Load Voltage |
280 V AC |
Minimum Load Voltage |
24 V AC |
Product Code |
7761774 |
Pack of |
1 Pc |
Manufacturer Part Number |
CWU2425-10 |
Standards Met |
CE, CSA, TUV, UL Listed |
