| Load Voltage | 1 to 80 V DC |
| Type of Product | Solid State Relay |
| Height | 37.4 mm |
| Depth | 12.7 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
1 to 80 V DC |
Type of Product |
Solid State Relay |
Height |
37.4 mm |
Depth |
12.7 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
DIN Rail |
Maximum Load Current |
5 A |
Country of Origin |
Mexico |
Length |
29 mm |
Leakage Current |
20 μA |
Maximum Operating Temperature |
+80°C |
Contact Configuration |
SPST |
Terminal Type |
Through Hole |
Minimum Operating Temperature |
-30°C |
Dimension |
29x12.7x37.4 mm |
Output Device |
MOSFET |
Switch Type |
DC |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
0.1 A |
Minimum Control Voltage |
18 V DC |
Maximum Turn On Time |
0.6 ms |
Control Voltage Range |
18 to 32 V DC |
Maximum Load Voltage |
80 V DC |
Minimum Load Voltage |
1 V DC |
Product Code |
7401312 |
Pack of |
1 Pc |
Package Type |
EMR |
Manufacturer Part Number |
ED10C5 |
