| Load Voltage | 24 to 280 V AC |
| Type of Product | Solid State Relay |
| No. of Pole | 1 |
| Height | 14.3 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
24 to 280 V AC |
Type of Product |
Solid State Relay |
No. of Pole |
1 |
Height |
14.3 mm |
Depth |
21.1 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
Panel Mount |
Series |
EL |
Maximum Load Current |
30 A dc |
Country of Origin |
Mexico |
Capacitance |
8 pF |
Special Features |
LED Input Status Indicator |
Length |
36.6 mm |
Leakage Current |
0.1 mA RMS |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Pad |
Minimum Operating Temperature |
-30°C |
Dimension |
36.6x21.1x14.3 mm |
Relay Type |
Solid State Relay |
Switch Type |
Instantaneous |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
27 V DC |
Minimum Load Current |
250mA RMS |
Minimum Control Voltage |
21 V DC |
Maximum Turn On Time |
1/2 cycle |
Control Voltage Range |
21 to 27 V DC |
Maximum Load Voltage |
280 V AC |
Minimum Load Voltage |
24 V AC |
Product Code |
1450593 |
Pack of |
1 Pc |
Manufacturer Part Number |
EL240A30R-24 |
Standards Met |
CE, CSA C22.2 No. 14, cULus Recognised E116950, EMC Compliant, EN 62314:2006, IEC 60335-1, IEC 61373, TUV, UL, UL Recognised |
