| Load Voltage | 24 to 280 V AC |
| Type of Product | Solid State Relay |
| Height | 12.7 mm |
| Depth | 5.1 mm |
Load Voltage |
24 to 280 V AC |
Type of Product |
Solid State Relay |
Height |
12.7 mm |
Depth |
5.1 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
PCB Mount |
Maximum Load Current |
1.5 A RMS |
Country of Origin |
Mexico |
Length |
24.1 mm |
Maximum Operating Temperature |
+80°C |
Minimum Operating Temperature |
-30°C |
Dimension |
24.1x5.1x12.7 mm |
Output Device |
SCR |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
10 V DC |
Minimum Load Current |
0.025 A |
Control Voltage Range |
4 to 10 V DC |
Maximum Load Voltage |
280 V RMS |
Product Code |
2181909 |
Pack of |
1 Pc |
Manufacturer Part Number |
ASO241 |
