| Load Voltage | 1 to 48 V DC |
| Type of Product | Solid State Relay |
| Height | 20 mm |
| Depth | 73.5 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
1 to 48 V DC |
Type of Product |
Solid State Relay |
Height |
20 mm |
Depth |
73.5 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
Panel Mount |
Series |
DP |
Maximum Load Current |
60 A |
Country of Origin |
Mexico |
Capacitance |
10 pF |
Special Features |
LED Input Status Indicator |
Length |
104 mm |
Leakage Current |
20 μA |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-30°C |
Dimension |
104x73.5x20 mm |
Relay Type |
Solid State Relay |
Output Device |
MOSFET |
Switch Type |
DC |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
0.10 A |
Minimum Control Voltage |
18 V DC |
Maximum Turn On Time |
200 ms |
Control Voltage Range |
18 to 32 V DC |
Maximum Load Voltage |
48 V DC |
Minimum Load Voltage |
1 V DC |
Product Code |
7719940 |
Pack of |
1 Pc |
Package Type |
Module |
Manufacturer Part Number |
DP4R60E60 |
