| Load Voltage | 24 to 280 VRMS |
| Type of Product | Solid State Interface Relay |
| Height | 90.3 mm |
| Depth | 18 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
24 to 280 VRMS |
Type of Product |
Solid State Interface Relay |
Height |
90.3 mm |
Depth |
18 mm |
Operating Temperature Range |
-30 to +80°C |
Mounting Type |
DIN Rail |
Series |
DR |
Maximum Load Current |
12 A RMS |
Country of Origin |
Mexico |
Capacitance |
10 pF |
Special Features |
AC or DC control, Fits standard 35mm DIN Rail |
Length |
83.7 mm |
Leakage Current |
0.1 mA RMS |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-30°C |
Dimension |
83.7x18x90.3 mm |
Output Device |
AC |
Switch Type |
Instantaneous |
Input Current |
9 to 11 mA |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
0.15 A RMS |
Minimum Control Voltage |
4 V DC |
Maximum Turn On Time |
1/2 cycle |
Control Voltage Range |
4 to 32 V DC |
Maximum Load Voltage |
280 V RMS |
Minimum Load Voltage |
24 V RMS |
Product Code |
7204105 |
Pack of |
1 Pc |
Manufacturer Part Number |
DR24D12R |
Standards Met |
CE, RoHS Compliant |
