| Load Voltage | 48 to 600 VRMS |
| Type of Product | Solid State Relay |
| No. of Pole | 1 |
| Height | 88.1 mm |
Load Voltage |
48 to 600 VRMS |
Type of Product |
Solid State Relay |
No. of Pole |
1 |
Height |
88.1 mm |
Depth |
120.7 mm |
Operating Temperature Range |
-20 to +80°C |
Mounting Type |
DIN Rail |
Series |
GNR 45mm |
Maximum Load Current |
45 A RMS |
Country of Origin |
Mexico |
Capacitance |
8 pF |
Special Features |
Built-In Overvoltage Protection, Direct Bond Copper Substrate, LED Input Status Indicator |
Length |
123.4 mm |
Leakage Current |
0.25 mA RMS |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-20°C |
Dimension |
123.4x120.7x88.1 mm |
Relay Type |
Solid State Relay |
Switch Type |
Zero Crossing |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
0.1 A RMS |
Minimum Control Voltage |
4 V DC |
Maximum Turn On Time |
1/2 cycle |
Control Voltage Range |
4 to 32 V DC |
Maximum Load Voltage |
600 V RMS |
Minimum Load Voltage |
48Vrms |
Product Code |
1450560 |
Pack of |
1 Pc |
Manufacturer Part Number |
GNR45DHZ |
Standards Met |
CE, CSA, UL |
