| Load Voltage | 48 to 530 V AC |
| Type of Product | Solid State Relay |
| No. of Pole | 1 |
| Height | 26.4 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Load Voltage |
48 to 530 V AC |
Type of Product |
Solid State Relay |
No. of Pole |
1 |
Height |
26.4 mm |
Depth |
57.3 mm |
Operating Temperature Range |
-40 to +80°C |
Mounting Type |
Panel Mount |
Series |
HD |
Maximum Load Current |
125 A |
Country of Origin |
Mexico |
Capacitance |
8 pF |
Special Features |
AC or DC Control, Direct Bond Copper Substrate, Direct Power Lead Frame, Epoxy-Free Design, Improved SEMS Screw & Washer, Redesigned Housing with Anti-Rotation Barriers |
Length |
44.5 mm |
Leakage Current |
1 mA RMS |
Maximum Operating Temperature |
+80°C |
Terminal Type |
Screw |
Minimum Operating Temperature |
-40°C |
Dimension |
44.5x57.3x26.4 mm |
Relay Type |
Solid State Relay |
Output Device |
SCR |
Switch Type |
Zero Cross |
Name of Manufacturer/Packer/Importer |
SENSATA/CRYDOM |
Maximum Control Voltage |
32 V DC |
Minimum Load Current |
150mA RMS |
Minimum Control Voltage |
4 V DC |
Maximum Turn On Time |
1/2 cycle |
Control Voltage Range |
4 to 32 V DC |
Maximum Load Voltage |
530 V AC |
Minimum Load Voltage |
48 V AC |
Product Code |
1450597 |
Pack of |
1 Pc |
Manufacturer Part Number |
HD48125K |
Standards Met |
CE, CSA LR 81689, cULus Recognised E116949, cULus Recognised E116950, EN 60950-1, IEC, IEC 60068-2-27, IEC 60068-2-6, IEC 61000-4-2, IEC 61000-4-4, IEC 62314, UL, VDE Approved 10143 UG |
